Custom Design Support

Standard cylinders don’t fit? Limited mounting space? Special working conditions? Tell us your requirements, and we’ll design a cylinder that works for you.

From Your Requirement to Drawing in 2 Days

Standard cylinders don't fit? Limited mounting space? Special working conditions?

Tell us your requirements, and we’ll design a cylinder that works for you.

————————————————————————————————————————————————————

Our Custom Design Process

1. Tell us your application

Vehicle modification, industrial automation, packaging machinery,

or any other application that needs a custom cylinder.

Describe your working conditions, and we’ll assess the feasibility.

2. Drawing in 2 days

Our engineers design based on your requirements

and provide 2D and 3D drawings along with a proposal.

3. You review, we revise

Not satisfied with the drawing? We’ll revise it until you approve it. Then we move to prototyping.

4. 7‑day prototyping — test it on your equipment

Sample production, testing, and shipping — all within one week. You test it on your actual equipment.

5. Feedback, refine, or scale

Issues with the sample? We keep optimizing. Works well? Move to volume production.

————————————————————————————————————————————————————

Why choose us for custom cylinders?

● No MOQ — Start with 1 piece, test, then scale

● 7-Day Prototyping — No waiting for weeks

● Design Support — We work until it fits — not just the first time, but every time

————————————————————————————————————————————————————

Common Customization Needs

Customization Type	Description
Non‑standard stroke	Standard stroke too short or too long? Customize to your exact need
Special mounting	Foot, flange, clevis, spherical rod eye whatever mounting interface you need
Special materials	Stainless steel rod, high‑temperature seals, food‑grade materials
Locking cylinder	For cab tilt, lifting, and other applications requiring safety locking
Extended piston rod	Special guidance needs? Piston rod length can be customized
Non‑standard port position	Standard port position doesn’t fit? Adjust it to your equipment layout
Don't see what you need?	Just tell us, and we’ll evaluate and provide a solution.
