Custom Cylinders By Feature

Custom Pneumatic Cylinders by Feature

Every OEM application places different demands on its pneumatic cylinders.Some require longer strokes or higher force, while others need non-standard mounting, controlled rod orientation, position-holding mechanisms, or materials suited to demanding operating conditions.Explore Fescolo custom pneumatic cylinders by the design features that matter most to your equipment. Our engineering team evaluates the complete application before recommending a suitable configuration.

Explore Custom Cylinder Features

Dimensions & Load

新新01.pngLong-Stroke Pneumatic Cylinders

Extended cylinder travel can create engineering challenges involving piston rod stability, alignment, mounting support, and load conditions.

Fescolo develops custom long-stroke pneumatic cylinders for sliding platforms, material transfer systems, and specialized OEM machinery. Our engineering experience includes a delivered 2,800 mm stroke cylinder project designed for demanding installation and operating conditions.

Explore Long-Stroke Cylinders →

03.pngLarge-Bore Pneumatic Cylinders

When an application requires higher linear force, a larger cylinder bore may be necessary.

Fescolo develops custom large-bore pneumatic cylinders based on operating pressure, required force, stroke length, and installation constraints. Our engineering review also considers piston rod strength, air consumption, structural stability, and mounting requirements.

Explore Large-Bore Cylinders →

0303.pngHeavy-Duty Pneumatic Cylinders

Heavy-duty performance requires more than a large bore diameter.

For demanding OEM equipment, Fescolo evaluates reinforced cylinder structures, piston rod configurations, mounting interfaces, guide support, and sealing arrangements based on actual loads, vibration, operating cycles, and environmental exposure.

Explore Heavy-Duty Cylinders →

Motion & Installation

Custom Mounting & Interfaces

Standard cylinder mounting dimensions do not always match specialized machinery.

Fescolo provides application-specific designs involving custom end caps, mounting brackets, rod-end connections, port positions, and installation dimensions. Special guidance arrangements, including extended front rod guides, can also be evaluated where required by the mechanical design.

Non-Rotating Pneumatic Cylinders

Some equipment requires the piston rod to maintain a controlled orientation during linear movement.

Fescolo develops non-rotating cylinder solutions using application-specific internal anti-rotation mechanisms or guided arrangements. Our experience includes a custom Ø100 mm bore, 420 mm stroke cylinder developed for an industrial discharge valve application.

Locking & Position-Holding Cylinders

Certain machinery requires the cylinder or driven mechanism to maintain position or resist unintended movement.

Fescolo can evaluate mechanical rod-locking arrangements and compatible position-holding solutions based on load conditions, movement direction, and equipment requirements.

Applications involving suspended loads or personnel safety require suitable independent safeguards and system-level validation.

Operating Conditions & Materials

Low-Temperature Pneumatic Cylinders

Low-temperature environments can affect seal flexibility, lubrication, and cylinder operation.

Fescolo evaluates suitable sealing materials, low-temperature lubricants, and structural configurations according to the specified operating conditions. Our project experience includes custom long-stroke cylinders designed for temperatures as low as −30°C.

High-Temperature Pneumatic Cylinders

Elevated temperatures can affect cylinder seals, lubricants, component materials, and long-term operating performance.

Fescolo evaluates high-temperature cylinder configurations based on ambient temperature, actual component exposure, operating cycles, and installation conditions. Suitable sealing materials, thermal protection, and structural modifications are selected according to the application requirements.

Stainless Steel Pneumatic Cylinders

Moisture, washdown processes, and corrosive environments may require specialized cylinder materials and surface protection.

Fescolo offers project-specific evaluation of stainless steel cylinder components, including suitable 304 or 316 stainless steel options, piston rod materials, surface finishes, and compatible sealing arrangements.

Material selection is based on the actual operating environment, cleaning procedures, and corrosion-resistance requirements.

Selected Engineering References

2,800 mm Long-Stroke Cylinder Project

A custom cylinder developed for a specialized sliding platform application, featuring a 2,800 mm stroke, low-temperature requirements, and additional support arrangements for long-stroke operation.

View Engineering Project →

Custom Non-Rotating Cylinder for Discharge Valves

A custom Ø100 mm bore, 420 mm stroke cylinder incorporating a specialized anti-rotation mechanism and application-specific mounting dimensions.

View Engineering Project →

Discuss Your Cylinder Requirements

Can't find the specific feature your equipment needs?

Every OEM application is different. Share your drawings, existing cylinder specifications, required force, stroke length, mounting dimensions, or operating conditions.

Our engineering team will review your requirements and provide initial technical feedback within 1–2 working days.

Prototype quantities can start from one piece, subject to project evaluation.

Start Your Custom Cylinder Project →
